| Vertical/Standard | |
| Size (mtr) | Size (ft) |
| 1.0 | 3’3″ |
| 1.5 | 4’10½” |
| 2.0 | 6′ 6″ |
| 2.5 | 8’1½” |
| 3.0 | 9′ 9″ |
VERTICAL /STANDARD
| Ledger | |||||
| Size (mtr) | Size (ft) | ||||
| 0.76 | 2’8″ | ||||
| 1.2 | 4′ 2″ | ||||
| 1.8 | 6′ | ||||
| 2.4 | 8′ | ||||
LEDGER
TRANSOM
| Transom | |||||
| Size (mtr) | Size (ft) | ||||
| 0.56 | 22″ | ||||
| 0.76 | 2′ 8″ | ||||
| 1.2 | 4’2″ | ||||
| Tie Bar | |||||
| Size (mtr) | Size (ft) | ||||
| 1.2 | 4’2″ | ||||
| 1.8 | 6′ | ||||
| 2.4 | 8′ | ||||
TIE BAR
DIAGONAL BRACES
| Diagonal Braces |
| Size (ft) |
| 6′ 0″ |
| 12′ 0″ |
| Return Transom |
| Size (ft) |
| 4’2″ |
| 2’8″ |
RETURN TRANSOM
BOWSTRING TRANSOM
| Bowstring Transom |
| Size (ft) |
| 6′ |
| 8′ |
| Batten Clamps |
| Size (ft) |
| 4’2″ |
| 2’8″ |
BATTEN CLAMPS
END TOE BOARD BRACKET
TOE BOARD BRACKET
1 BOARD BRACKET
2 BOARD STAGE BRACKET
3 BOARD STAGE BRACKET
4’2″ LADDER ACCESS TRANSOM
INTERNAL CORNER FILLER 1×1 Board
INTERNAL CORNER FILLER 2×2 Board
INTERNAL CORNER FILLER 3×3 Board
2/3 BOARD BRACKET BATTEN CLAMP
HAND RAIL SHOE
STEEL PALLETS L 940XW 940XH 675
FLAT PALLET ( 3 PARTS)
